Medical Gases

MEDICAL GASES


Al Rahim Gases is the authorized distributor of Medical Gases to the health sector for more than 6 years. We have a vast range of medical gases to provide our customers with; Oxygen, Nitrogen, CO2, Nitrous oxide & Entonox. We supply these gases in bulk and as well as in cylinders.

MEDICAL OXYGEN

Oxygen Gas is widely used in hospitals to aid in patient care, for curing and prevention of hypoxemia and hypoxia. Several other medical conditions require the use of medical Oxygen to sustain life.

NITROUS OXIDE

Nitrous Oxide Gas is used in surgery and dentistry as an anaesthetic and analgesic agent. It is used in the relief of sever pain like wound dressing, tooth extraction.

ENTONOX

Entonox Gas is a pain relieving gas mixed with nitrous Oxide and Oxygen. It is given to patients through inhalation. It used as a pain reliever in short term pain including dental procedures child birth

CARBON DOIXIDE

Carbon Dioxide Gas is used as an insufflation gas for minimal invasive surgery such as endoscopy arthroscopy to enlarge and stabilize body cavities for better visibility of the surgical fields.

Compressed Medical Oxygen Standards

Specifications Standard Euoropean pharmacopoeia 1999 Our standard
Oxygen purity 99.5% (min) 99.5% (min)
Moisture ≤ 67 vpm ≤ 50 vpm
Carbon Dioxide ≤ 300 vpm ≤ 300 vpm
Carbon Monoxide ≤ 5 vpm ≤5 vpm
Odour None None

Compressed Nitrous Oxide Standards

Specifications Standard Euoropean pharmacopoeia 1999 Our standard
N2O Purity 98.0% (min) 98.0% (min)
Moisture ≤ 67 vpm ≤ 120 vpm
Carbon Dioxide ≤ 300 vpm ≤ 300 vpm
Carbon Monoxide ≤ 5 vpm < 10 vpm
Nitric Oxide < 2 vpm < 2 vpm

Range of Cylinders Provided for Compressed Medical Gases

Oxygen 5 I water capacity 10 I water capacity 47 I water capacity
Gas capacity in CUM 0.8496 1.699 6.796
Valve Operation Pin Index Side and top outlet Side and top outlet
Cylinder pressure full (bar) 137 137 137
Nitrous Oxide
Gas capacity in CUM 0.8496 1.699 6.796
Valve Operation Pin Index Wheel type Wheel type
Cylinder pressure full (bar) 80 80 80
Air
Gas capacity in CUM 0.8496 1.699 6.796
Valve Operation Pin Index Side and top outlet Side and top outlet
Cylinder pressure full (bar) 137 137 137
Entonox® (50% O 2 /50%NO) 2
Gas capacity in CUM 0.8496 1.699 6.796
Valve Operation Pin Index Pin Index Pin Index
Cylinder pressure full (bar) 137 137 137

AL RAHIM GASES MADE GAS SUPPLY EASY


Let Us Manage Your Gas Supplies
Or
Cylinder Fleet For You
